ZOOMRY drum pulleys feature an integrated hub machined from solid steel, reducing welding points and improving structural integrity compared to conventional fabricated designs. This modern engineering approach reduces weight while maintaining strength — lowering both material cost and freight expense — and a single model can serve multiple belt widths from 400mm to 2,000mm, simplifying inventory management for operations running belt conveyor systems across multiple sites.

---

Why Choose a Drum Pulley Over a Conventional Welded Pulley?

Traditional Conveyor Pulleys rely on welded hub-to-shell connections — multiple weld points that introduce residual stresses, potential weak spots, and quality variability depending on welder skill. ZOOMRY's drum pulley eliminates these issues by machining the hub and shaft interface from a single piece of solid steel. The result is a pulley with fewer failure points, consistent quality, and a streamlined profile that reduces overall weight without compromising load capacity.

For procurement and maintenance teams, the real advantage is inventory simplification. A single drum pulley model can serve as a drive pulley, tail pulley, or take-up pulley across multiple belt widths — reducing the number of spare parts that need to be stocked. With rubber or ceramic lagging options available, the same base pulley can be configured for different positions in the conveyor system.

---

Design Features

• Less welding – integrated hub machined from a single piece of steel, eliminating welded connections and associated residual stresses
• Decreased weight – modern engineering positions material where it is needed most, reducing dead weight and lowering freight costs
• Cost reduction – no unnecessary extra-heavy construction when not required, providing an economical alternative for non-drive and moderate-duty positions
• Reduced inventory – a single model can function in multiple applications across belt widths from 400mm to 2,000mm, simplifying spare parts management

---

Where Are Drum Pulleys Most Commonly Used?

Drum pulleys with integrated hub design are particularly well suited for applications where moderate loads, clean environments, and cost-effective procurement are priorities:

• Non-drive positions – tail pulleys, bend pulleys, and take-up pulleys where the integrated hub design provides adequate strength without the extra weight of heavy-duty drive pulleys
• Aggregate & sand conveyors – standard-duty applications in quarries and sand & gravel operations where cost-effective, reliable performance is the priority
• Multi-site operations – companies managing conveyors across multiple locations benefit from the "one model, many uses" inventory simplification
• Cement plants – moderate-duty transfer conveyors between processing stages where corrosion-resistant coatings and rubber lagging extend service life

---

Specifications – Pulley Diameter vs Belt Width

The following table shows which drum pulley diameters are available for different belt widths. "√" indicates a standard match. Custom configurations are available upon request.

---
