Equipped with mechanical + hydraulic dual-trigger technology, it achieves millisecond-level response of 0.2-0.3 seconds, realizing 100% bidirectional capture and locking across the entire belt surface. It is compatible with full belt widths of 650-2200mm and full inclination angles of -25~+32°, with graded braking force ranging from 50-1500kN covering light, medium and heavy loads. It fundamentally eliminates the risks of material falling, equipment damage and personal safety hazards caused by belt breakage and slipping, making it an essential safety protection equipment for bulk material transportation in mining, port, power and building materials industries.
Core Advantages of Belt Arrestor
ZOOMRY Belt Arrestor features sufficient safety redundancy in rated braking force. Verified by mechanical simulation, it can stably complete capture even under extreme working conditions exceeding the design load. With an inclination angle coverage of -25~+32°, it fully covers scenarios such as upward conveying, downward conveying and horizontal conveying. The installation spacing can be dynamically adjusted according to the inclination angle to ensure no protection blind spots. The product strictly complies with core domestic and international standards, holding multiple authoritative certifications including CE, ATEX Explosion-proof Certification and MA Coal Mine Safety Mark, fully meeting the safety specifications of major global markets without the need for additional adaptation and modification for export.
As a core supporting component of ZOOMRY's complete bulk material transportation equipment, it perfectly collaborates with self-owned host products such as belt conveyors, bucket wheel stacker-reclaimers and telescopic stackers. With standardized size interfaces, it can be quickly matched without additional modification. It is also compatible with various domestic and foreign brand conveyors and different types of belts, with a belt strength adaptation range of 800-4000N/mm, enabling precise matching from light to heavy load scenarios. Wear parts adopt a modular design and share the supply chain with ZOOMRY's existing components, featuring strong versatility and convenient procurement and replacement. The product has a design life of no less than 10 years, is maintenance-free for daily use, requiring only regular visual inspection and brake block wear detection, and its long-term operating cost is significantly lower than that of similar products.
Technical Core of Belt Arrestor
Dual-Mode Intelligent Trigger Mechanism
It flexibly adapts to two trigger modes according to different load scenarios to ensure accurate and efficient response. Light-load belt arrestors (rated braking force 50-200kN) adopt pure mechanical + gravity drive, requiring no external power supply, hydraulic station or other auxiliary equipment. Triggered by changes in belt tension and gravity sensing, they can work reliably in extreme environments such as no electricity, humid salt spray and -40℃ low temperature, avoiding failure caused by electromagnetic interference or power interruption. General-purpose belt arrestors (300-600kN) and heavy-load models (800-1500kN) incorporate hydraulic auxiliary triggering, compressing the response time to 0.2-0.3 seconds, far exceeding the industry average. The hydraulic system adopts an explosion-proof design, and together with tension monitoring sensors, it captures fault signals in real time to realize a fully automated "monitoring-judgment-trigger" process, adapting to high-throughput and high-belt-speed heavy-load scenarios.
Full Belt Surface Bidirectional Locking Structure
The equipment adopts a symmetrical wedge-shaped brake block structure to achieve 100% full belt surface bidirectional capture. After triggering, the brake blocks on both sides synchronously tighten towards the center of the belt, not only locking the carrying section of the belt to prevent material rollover and falling, but also fixing the return section of the belt to avoid stacking and winding around the drum, completely eliminating the loophole of "one-sided slip". The brake blocks are made of REACH-compliant polyurethane and rubber composite materials, subjected to special wear-resistant treatment, with a slip resistance coefficient of no less than 0.8, balancing braking friction and belt protection to avoid secondary damage. The braking deceleration is strictly controlled at 0.2-0.5m/s², and the inertial impact force is absorbed through the buffer structure to prevent equipment resonance or structural deformation.
Convenient Installation and Strong Environmental Adaptability
The product frame is made of Q235B/Q355B high-strength section steel and alloy steel, inspected by ultrasonic flaw detection, with defects meeting JB/T4730.3 Level I standard, capable of withstanding instantaneous impact force. Two frame types are available: fixed and suspended. Light-load and general-purpose models support quick-installation fixture mounting, requiring no welding or drilling, and a single set can be deployed within 2 hours, which can be easily adapted to existing belt conveyors; heavy-load models adopt bolt fixing + foundation reinforcement design to ensure installation stability in high-inclination and high-throughput scenarios. The product has a protection level of IP65-IP67 and a corrosion resistance level in line with ISO 12944-6 C4-C5-M standard. Key components undergo double treatment of galvanizing + spray coating, capable of resisting erosion from harsh environments such as dust, salt spray and corrosive gases, with an operating temperature range of -40~+60℃, adapting to different climate regions around the world.
Core Product Parameters Table
| Series Type | Rated Braking Force (kN) | Applicable Belt Width (mm) | Trigger Mode | Operating Temperature (℃) | Applicable Belt Strength (N/mm) | Installation Type |
|---|---|---|---|---|---|---|
| Light-Load | 50-200 | 650-1200 | Pure Mechanical + Gravity Drive | -40~+60 | 800-2000 | Fixed/Suspended (Quick Installation) |
| General-Purpose | 300-600 | 800-1600 | Mechanical + Hydraulic Auxiliary | -40~+60 | 1500-3000 | Fixed/Suspended (Quick Installation) |
| Heavy-Load | 800-1500 | 1400-2200 | Mechanical + Hydraulic Auxiliary | -40~+60 | 2500-4000 | Fixed (Bolt + Foundation Reinforcement) |
Applicable Scenarios
Mining Industry
Mining conveyor lines are mostly high-inclination and high-throughput working conditions, with large material impact, fast belt wear and prominent belt breakage risks. Relying on dual-trigger technology, ZOOMRY's heavy-load belt arrestor can quickly lock the belt at the moment of breakage, avoiding a large amount of material falling to damage equipment or cause collapse risks. Meeting the explosion-proof requirements of underground coal mines, the product has passed ATEX and MA certifications, with a protection level of IP67, adapting to high-dust and humid environments, and working in collaboration with self-owned conveying equipment to ensure production continuity.
Port Industry
Belt conveyors supporting ship loaders and stackers at port bulk terminals are characterized by large belt width, high belt speed and complex operating environment. Belt breakage accidents may cause materials to fall into the ocean or yards, resulting in environmental pollution and operation interruption. ZOOMRY's general-purpose and heavy-load belt arrestors adopt anti-corrosion coating and high-protection design to resist salt spray erosion. The full belt surface bidirectional capture avoids belt winding around the drum, and links with the automatic control system to realize fault alarm and emergency shutdown, ensuring safe and efficient terminal operations.
Power Industry
Coal conveying systems in thermal power plants and nuclear power plants need to operate continuously for 24 hours, and belt breakage accidents will directly lead to power generation interruption. ZOOMRY's general-purpose belt arrestor is suitable for medium and low inclination angle working conditions in power plants. The pure mechanical + gravity drive mode does not rely on external power supply, avoiding protection failure during power outages. The product links with the PLC control system, and synchronously cuts off the power supply and sends remote alarms when triggered, facilitating operation and maintenance personnel to quickly handle and reduce downtime.
Building Materials Industry
Aggregate and clinker conveyor lines in cement plants and mixing stations mostly handle corrosive or highly abrasive materials. ZOOMRY's light-load and general-purpose belt arrestors can be flexibly adapted according to material characteristics, with core components made of anti-corrosion or high-wear-resistant materials to extend service life. Used in conjunction with self-owned feeders and unloaders, they are compatible with belt conveyors of different widths, avoiding production line shutdown caused by belt breakage accidents.
Belt Arrestor Selection Guide
- Confirm the core parameters of the conveyor and materials. Clarify the belt width, inclination angle, belt speed and belt strength of the belt conveyor, as well as the material type and weight per unit length. Determine the minimum braking force through mechanical calculation to ensure the selected model matches the requirements, avoiding waste or insufficient protection.
- Adapt to working conditions, environment and compliance requirements. For explosion-proof scenarios, select models with ATEX or MA certification; for coastal, port and other scenarios, prioritize products with high corrosion resistance level; for exported products, confirm the corresponding certification and standard requirements of the target market.
- Consider host matching and maintenance needs. For ZOOMRY's own hosts, directly select the corresponding adapted model; for adapting to other brand hosts, provide parameters such as frame size and installation space. For remote unattended scenarios, models with intelligent diagnosis function can be selected; for mobile belt conveyors, lightweight and quick-installation frames are preferred.
Choose ZOOMRY
ZOOMRY Belt Arrestor takes international standards as the R&D and production benchmark to ensure global market access and safety reliability.
It fully complies with core domestic and international standards, strictly following China's NB/T 11464-2023, EU EN 12895, North American ASTM D3794, international ISO 5048 and other standards. Parameter design and performance testing are carried out in accordance with the highest standards, benchmarking with international similar products in performance. It has complete authoritative certification qualifications, all certifications are issued by third-party authoritative institutions, and the certificates can be queried and verified globally, providing customers with reliable compliance guarantees.
It has established a production control process in line with the ISO 9001 quality system. Core components undergo multiple inspection processes, and simulated belt breakage tests are conducted before leaving the factory. Key indicators are recorded, and complete test reports can be provided to customers to ensure transparent and credible product quality.
After-Sales Support and Service Commitment
Adhering to the customer-centric concept, ZOOMRY provides comprehensive service support for global customers:
-
Professional technical consultation and customized services. A team of senior engineers provides customers with support such as selection plans, installation drawings and mechanical calculation reports, offers customized design services for special working conditions, and follows up to meet personalized needs throughout the process.
-
Convenient supply of wear parts. Standardized and generalized wear parts can be quickly procured, with simple replacement processes that do not require professional tools. Operation and maintenance personnel can operate after simple training.
-
7×24 global technical support. Customers can obtain troubleshooting, technical guidance and other services at any time. For large-scale projects, engineers can be dispatched to provide on-site installation guidance and commissioning training, and maintenance manuals are regularly released to help customers improve their operation and maintenance capabilities.
-
Comprehensive quality assurance and lifelong maintenance commitment. Light-load models come with a 2-year warranty, general-purpose models with a 3-year warranty, and heavy-load models with a 5-year warranty. Free repair or replacement is provided for non-human-caused failures during the warranty period. Lifelong maintenance services are offered after the warranty period, with only reasonable component costs charged.
