Grasshopper Conveyor

portable conveyor

Zoomry Portable Conveyor is specifically designed for mining, construction aggregate stacking, and solid waste processing scenarios. The equipment integrates a folding boom structure with a heavy-duty mobile chassis, enabling dynamic stacking of materials at 200-550 tons/hour, reducing labor costs by over 50%, and helping users achieve rapid return on investment.
  • Product Detail

Zoomry Portable Conveyor is specifically designed for mining, construction aggregate stacking, and solid waste processing scenarios. The equipment integrates a folding boom structure with a heavy-duty mobile chassis, enabling dynamic stacking of materials at 200-550 tons/hour, reducing labor costs by over 50%, and helping users achieve rapid return on investment.

portable conveyor

Product Features of Portable Conveyor

All-Terrain Mobility Platform

Equipped with a box-beam reinforced chassis and optional track or off-road tire drive systems (dual-mode compatible), it overcomes 18° slope limits. Structurally optimized via CAE, the track version has ground contact pressure ≤0.08MPa, while the tire version offers 320mm ground clearance. Ensures stable performance in muddy mining areas and demolition sites with a maximum payload of 35 tons.

Intelligent Telescopic Boom Structure

Proprietary folding technology enables transport/operation mode conversion: Transport length compacted to 12m for road compliance; operational extension of 15-30m (customizable), stacking height range 6.5-8m. Integrated hydraulic self-leveling module maintains horizontal accuracy within ±1° on slopes up to 8°, ensuring uniform material stacking.

High-Efficiency Feed Integration

0.8m low-position receiving hopper interfaces directly with various construction machinery. Three-way splash guards reduce material spillage by 15%. Lined with 6mm wear-resistant alloy plates (HRC 58-62), its service life exceeds 10,000 hours when conveying abrasive materials like iron ore.

Eco-Friendly Power Options

Diesel version features Cummins QSB6.7 engine (China IV certified), offering 15% better fuel efficiency than industry average at 220kW continuous power. Electric version operates on 380V/50Hz, with smart soft-start module supporting 150% instantaneous overload, reducing operating costs to 60% of diesel models.

Precision Stacking Control

1.0-3.0m/s infinitely variable speed belt coupled with hydraulic pitch mechanism (-5°~+25°) enables stepped stacking accuracy. Integrated 200m remote control with emergency stop function (response time ≤0.3s) allows operators to complete slewing, stacking, and all other functions remotely.

Smart Maintenance Architecture

Modular quick-release design enables Conveyor Belt replacement in ≤2 hours. Centralized lubrication system covers 32 critical points, extending maintenance intervals to 500 hours. Standard OBD-II interface monitors 67 operating parameters and provides early warnings for 90% of mechanical faults 30 hours in advance.

Scenario-Based Solutions

Mining Haulage Coordination

  • Typical Materials: Magnetite, marble, basalt
  • Technical Requirements: Mobile conveyor between extraction zones and crushing stations, throughput ≥300t/h, must traverse complex terrains >18°

Aggregate Smart Stacking

  • Typical Materials: Manufactured sand, cement clinker, concrete aggregates
  • Technical Requirements: Achieve 6-8m anti-segregation stacking in confined spaces with integrated dust suppression to meet environmental standards

Solid Waste Recycling

  • Typical Materials: Demolition debris, smelting slag, industrial dust
  • Technical Requirements: Corrosion-resistant and anti-clogging design, adjustable stacking height for multi-level storage solutions

Equipment Performance Parameters

Model Throughput (t/h) Working Span (m) Drive Power (kW) Chassis Power (kW) Gradeability Stacking Height (m) Belt Speed (m/s)
ZR65D 200 15/20/25 18.5 11 18° 6.5/8.0 2.0
ZR80D 300 15/20/25 22 11 18° 6.5/8.0 2.0
ZR100D 400 15/20/25 30 15 18° 6.5/8.0 2.5
ZR120D 550 15/20/25 37 15 18° 6.5/8.0 2.5

Value Assurance System

Military-Grade Manufacturing

Chassis uses special structural steel with non-destructive testing of critical welds. Triple-layer anti-corrosion coating withstands harsh field environments. Articulated booms support 15-30m span customization. Ultra-low hopper compatible with mainstream construction machinery feeding.

Rapid-Response Service Network

Service Module Time Commitment Industry Benchmark
Solution Design 24hr Technical Proposal Industry norm: 72hr
Equipment Delivery 15-Day Standard Cycle Standard: ≥30 Days
Troubleshooting 2hr Remote Diagnosis + 48hr On-site Typical: 72hr On-site
Parts Supply 2000+ SKUs Delivered in 72hr Typical: 1-2 Weeks

Extended Warranty

5-year machine warranty + 5-year extension for core transmission components. Covers wear parts replacement (including liners/screens) except operator misuse, eliminating maintenance concerns.
