Snub pulleys are used to increase the wrap angle of the Conveyor Belt around the drive pulley, reducing the pulling force of the belt and optimizing the cost of your entire conveying system. By reducing belt tension, a conveyor belt with a lower belt strength can be used for the same purpose — lowering both initial investment and long-term operating costs. Mounted close to the drive pulley on the return side of the belt, the snub pulley's primary job is to increase traction while maximizing conveyor component life.
ZOOMRY Snub Pulley — Increases Drive Pulley Wrap Angle, Reduces Belt Tension, 50,000+ Hour Service Life
How Does a Snub Pulley Optimize Your Conveyor System?
In a belt conveyor system, the drive pulley relies on friction between the pulley surface and the belt to transmit power. When the wrap angle — the arc of belt contact around the drive pulley — is insufficient, the belt can slip under heavy load, causing premature wear and energy loss. The snub pulley solves this by pressing against the return side of the belt near the drive pulley, forcing the belt around more of the drive pulley's circumference.
This increased wrap angle provides greater traction without increasing belt tension, which means the entire system can operate with a lighter, more cost-effective belt. For operations in mining, cement, and quarry environments where high-capacity conveying is essential, a properly configured snub pulley can significantly extend the life of both the belt and the drive components.
Key Benefits of ZOOMRY Snub Pulleys
- Optimized Traction – increases the drive pulley wrap angle, improving belt grip without additional tension
- Reduced Belt Tension – allows the use of a lighter, more economical conveyor belt for the same application
- Extended Component Life – lower tension reduces stress on bearings, shafts, and belt splices across the entire system
- Flexible Surface Options – available in flat rubber lagging, ceramic lagging, or diamond rubber lagging to suit different operating conditions
- Bulk Order Capability – we can easily handle bulk orders at competitive prices with consistent ISO 9001 quality
Specification
| Belt Conveyor Snub Pulley | |
|---|---|
| Items | Content |
| Belt Width | 500-2800 mm (19-110.2 inch) |
| Pulley Length | 500-3200 mm (19-125.9 inch) |
| Diameter | 200-1800 mm (7.8-70.8 inch) |
| Standard | ISO 9001, CEMA, DIN, TUV, etc. |
| Working Life | More than 50,000 hours |
| Surface | Flat Rubber Lagged, Ceramic Lagged, Diamond Rubber Lagged, etc. |
| Main Material | Carbon Steel / 16Mn |
| Length of conveyor snub pulley depends on the width of conveyor belt. You can get snub pulleys with hot vulcanized rubber lagging, plain or grooved, as required by client. | |
Product Video
Related Industry Solutions
Need Custom Snub Pulleys?
Contact ZOOMRY for snub pulleys designed to match your specific belt width, diameter, and lagging requirements.
